Fontana SmartFlush FX Grey Automatic Sensor Urinal Flush Valve

Transform the traditional experience of public restrooms with Fontana SmartFlush FX™. It offered in a sleek grey finish to match all architectural styles. The system is built to last, with a durable 304 stainless steel panel suited for high-use environments, and accompanied by a wrapped electroplated plastic frame, providing both durability and aesthetic regard. The unit has been designed for wall mounting so it can be discreetly positioned on the adjacent wall surface for clean lines and simple interior design. Another advantage of this unit is the induction system operating on DC powered four AA alkaline batteries, creating wireless convenience and reliability with sensor positions. The unit comes with a solid brass cartridge, also designed for high-use environments. With water conservation in mind, the unit and software with adjustable timing will work efficiently, conservatively, and sustainably, without compromising effectiveness. Its discrete nature also creates two beneficial advantages: it keeps appliances and surfaces to a minimum for vandalism, and assists restroom hygiene on and within surfaces themselves. As a case for architects, builders, and operators that are progressive in their restroom strategies, this unit provides opportunities for style, durability, and automation, and is efficient for enhancing overall restroom function.

Advanced Flush Intelligence in a Bold Grey Tone

• Brand Name: FontanaShowers®
• Model Number: FS8116GR
• Design Style: Contemporary
• Product Type: Urinal Flush Valve
• Flush Valve Type: Automatic Sensor
• Finish: Grey
• Material: 304 SS Panel + Electroplated Plastics Frame
• Flush Time: Adjustable
• Installation Type: Wall Mounted
• Electronic Induction Type: DC
• Power Supply: DC:6V (4xAA Alkaline Batteries).
• Cartridge: Brass
• Special Features: Concealed, Touchless, Water Saving
• Front View Width: 5.12"
• Front View Height: 5.12"
• Side View Height: 4.49"
• Side View Width: 4.88"
• Total Depth: 2.95"
• Main Body Depth: 1.48"
• Front Face Depth: 0.59"
• Panel Thickness: 0.24"
