Fontana Commercial Touch Free Automatic Hand Sanitizer Soap Dispenser
Incorporate Automation in Your Commercial Bathroom! Give your Commercial bathroom an elegant glance with bathroom upgrades and fixtures. Be it Commercial Restaurant Bathrooms, Office Building Bathrooms, or Any Public Bathroom. This is one of the trendiest finishes across bathroom design styles. The LED light flashes two times at half-second intervals during sensor operation to indicate low battery, and it flashes five times after activation to signal low soap. This dispenser is ideal for hygienic hand washing. When it comes to new commercial bathroom upgrades, FontanaShowers is offering the shape, finish, and style that you've been looking for. It is our goal to provide the customer with not only excellent products but also a leading lifestyle. This has an elegant design and elevates the appeal of any decor made from the highest quality and for great taste. Ideal for commercial use applications in public restrooms, restaurants, office buildings, and public facilities. Fits all US Standard plumbing. It comes with super seal technology inside, capable of delivering superior performance with solid construction for long durability that will upgrade your bathroom with a modern and cool look for a long period of time.
Fontana Commercial Touch Free Automatic Hand Sanitizer Soap Dispenser Features:
- Brand Name: FontanaShowers®
- Model Number: FS1017
- Feature: Touchless Soap Dispenser
- Main Material: Solid Brass Metal
- Finish: Matte Black
- Dispenser Type: Automatic Soap Dispenser
- Pump Material: Brass
- Surface Treatment: Polished
- Soap Bottle Capacity: 1800 ml
- Installation Type: Wall Mounted
- Working Mode: IR sensor
- Power Supply: AC 100V–240V / 50–60Hz; DC 6V
- Active Mode: ≤3.5W
- Static Mode: ≤0.8mW
- Sensing Range: 10–20 cm
- Soap Dispense Volume: 4 Settings
- Viscosity of Liquid Soap: 1,000–2,000 cp (mPa·s)
- Ambient Temperature: 1–55 °C
- Ambient Humidity: Max 90% RH
- Tap Height: 20mm
- Tap Width: 40mm
- Tap Depth: 220mm
- Motor Case Height: 307mm
- Motor Case Width: 90mm
- Motor Case Depth: 106mm
- Spout Projection:118 mm (4.65")
- Spout Mount Height: 198 mm (7.8")
- Bracket Width: 62 mm (2.44")
- Control Box Min. Height: 315 mm (12.40") Above Floor
- Usage: Commercial
|
|
|
