FontanaAuraFlow Matte White Double Touchless Sensor Bathroom Faucet
The FontanaAuraFlow™ Matte White Auto is a touchless faucet that allows sanitation, efficiency, and aesthetics to thrive in commercial bathrooms. To say that this is made from durable brass with a matte white finish is an understatement; the strength and contemporary look this presents can be seamlessly integrated into any interior design.
An intelligent infrared sensor has a range of adjustable 18±2 cm that offers hands-free operation, allowing for minimal contact with surfaces and minimal risk of cross-contamination. The faucet features an easy deck mount installation with only one hole; it also has the flexibility to use AC220V or DC6V electrometric configurations. The features include the ability to be used with 50% less water, still and work reliably easily with included maximum pressure and reliability and durability tested for use at 0.05~ 0.7 MPa pressure with a strength of 120 KG / m over-pressure performance as part of the water tap construction. The measurements are 6.30" × 6.30" × 5.12", so it can be easily integrated into various layouts. This is a great example of the ideal combination of functionality, reliability, and elegance from a widely trusted and used commercial fixture.
FontanaAuraFlow™ Matte White Dual Sensor Automatic Faucet FAQ
Dual-Sensor Calibration, IP65 Valve Protection; Matte White Surface Care
The FontanaAuraFlow™ Matte White automatic faucet combines solid-brass construction, adjustable dual-sensor activation, single-hole deck mounting, AC220V or DC6V power, IP65 waterproof protection, and reliable operation across a 0.05–0.7 MPa water-pressure range.
How should the adjustable 18 ± 2 cm dual-sensor range be commissioned?
Complete sensor calibration after the basin, backsplash, mirror, soap dispenser, lighting, and countertop accessories are installed. Test both detection points from normal hand-entry positions and reduce the sensing distance if reflective surfaces, nearby movement, or the basin itself causes activation outside the intended washing zone.
What should be checked if the two sensors respond at different distances?
Clean both infrared sensor windows, confirm that the faucet body is securely mounted, verify stable AC220V or DC6V power, and inspect the electrical connections. Surface contamination, loose wiring, fixture misalignment, reflective objects, or changing ambient light can alter either sensor’s effective detection range.
How should the faucet be tested across its 0.05–0.7 MPa operating-pressure range?
Flush the supply branch before connection, inspect the inlet filter, and test the faucet under dynamic pressure. Confirm stable discharge, immediate activation, and complete valve closure after hand removal while checking all supply and control-box connections for leakage or pressure-related movement.
How should the Matte White finish be cleaned without creating glossy or discolored areas?
Wipe the exposed surface with a soft damp microfiber cloth and dry it immediately. Use diluted pH-neutral soap only and avoid abrasive pads, acidic descalers, bleach, ammonia, alcohol-heavy cleaners, steel wool, polishing compounds, and concentrated disinfectants that may alter the uniform matte coating.
Read More
- Brand Name: FontanaShowers®
- Model Number: FS7960MW
- Finish: Matte White
- Style: Contemporary
- Type: Touchless Bathroom Faucet
- Material: Brass
- Installation Type: Deck Mounted
- Number of Holes for Installation: One Hole
- Sensor Distance: 18±2cm(Adjustable)
- Power Input: AC220V & DC6V
- Sensor Type: Touchless
- Features: Electric Faucets, Metered Faucets, Sense Faucets
- Faucet Mount: Single Hole
- Application: Commercial Bathroom
- Installing Hole: 1"(25 mm)
- Water Saving: 50%
- Water Pressure: 0.05–0.7 MPa
- Over-Pressure Testing: 12 KG/m
- Waterproof: IP65
- Faucet Lifetime: ≥ 500,000 times
- Faucet Size: 6.30" × 6.30" × 5.12" (160 × 160 × 130 mm)
- ADA Compliant
