Fontana HarmonyTrio Brushed Gold 3 in 1 Sensor Activated Combo Soap, Water & Dryer Brushed Gold
The Fontana HarmonyTrio™ Brushed Gold Set from FontanaShowers® is an upscale product that delivers style, cleanliness, and smart features all in one package. The deck-mounted set features a stunning brushed gold finish that incorporates an effortless touchless faucet, an automatic soap dispenser, and a high speed hand dryer to keep the experience fully touchless. With a water pressure of 0.05–0.6 MPA, the faucet runs effortlessly, optimising flow temperatures between 0.1–50°C.
The soap dispenser comes with a spacious 1L tank for frequent use, and the hand dryer incorporates a powerful brushless motor that spins at 38,000 RPM, producing an astounding airflow of 90m/s to dry hands in 10–15 seconds at a comfortable temperature between 30–40°C and only creates 75dB of sound. It even comes equipped with a HEPA filter that guarantees purified drying air, while only consuming 1W in standby. Built for ADA compliance, with an IP rating and compact sizing (water tap height 4.92 in, dispenser 4.92 in, dryer 5.91 in), this solution makes it extremely easy to install and use. The Fontana HarmonyTrio™ is the perfect marriage of luxury design and touchless technology to provide the convenience, cleanliness, and efficiency you are looking for in one solution.
Fontana HarmonyTrio™ Brushed Gold 3-in-1 Touchless System FAQ
Sensor-Zone Separation, HEPA Airflow Verification; Brushed Gold Finish Care
The Fontana HarmonyTrio™ Brushed Gold system integrates an automatic soap dispenser, touchless water faucet, and high-speed hand dryer within a brass deck-mounted configuration featuring a 1-liter soap reservoir, 38,000 RPM motor, 90 m/s airflow, HEPA filtration, and AC or DC power compatibility.
How should the soap, water, and dryer sensing zones be commissioned?
Complete sensor testing after the basin, countertop, mirror, backsplash, and surrounding accessories are installed. Verify each function independently so normal hand movement activates only the intended soap, water, or drying outlet without cross-triggering adjacent sensors or responding to reflective surfaces.
What hydraulic checks are required across the 0.05–0.6 MPa pressure range?
Flush the water branch before connecting the faucet, inspect the inlet filter, fully open the service stop, and test under dynamic operating pressure. Restricted tubing, residual construction debris, or unstable pressure can weaken discharge and interfere with reliable automatic valve closure.
What should be inspected if drying exceeds the expected 10–15 second cycle?
Check the HEPA filter, air intake, outlet path, undercounter ventilation, and electrical supply before evaluating the motor. A loaded filter, restricted airflow, unstable voltage, or obstructed motor enclosure can reduce the designed 90 m/s air velocity and extend drying time.
How should the Brushed Gold finish be cleaned without changing its grain?
Remove soap residue, water spots, and fingerprints with a soft damp microfiber cloth, wiping in the direction of the brushed surface. Dry each fixture immediately and avoid abrasive pads, acidic descalers, bleach, ammonia, steel wool, metal polish, and concentrated disinfectants.
Read More
- Brand Name: FontanaShowers®
- Model Number: FS9902BG
- Finish: Brushed Gold
- Feature: Touchless Faucet, Soap Dispenser & Dryer (3-in-1)
- Material: Brass
- Installation Type: Deck Mount
- Voltage: 220–240V / DC6V (AC & DC Compatible)
- Frequency: 50Hz
- Total Power (Dryer): 1300W
- Standby Power: 1W
- Water Pressure (Faucet): 0.05–0.6 MPA
- Operating Temperature (Water): 0.1–50°C
- Soap Volume Capacity: 1L
- Dryer RPM: 38,000
- Hand Dryer Air Speed: 90 m/s
- Dryer Temperature: 30–40°C
- Noise Level: 75 dB
- Filter: HEPA
- Hand Dryer Dry Time: 10–15s
- Tap Height: Water Tap: 4.92 in | Dispenser: 4.92 in | Dryer: 5.91 in
- Tap Width: Water Tap: 1.97 in | Dispenser: 1.57 in | Dryer: 1.97 in
- Tap Depth: Water Tap: 6.69 in | Dispenser: 4.92 in | Dryer: 7.48 in
- Motor Case Height: Water Tap: 5.71 in | Dryer: 11.42 in
- Motor Case Width: Water Tap: 4.59 in | Dryer: 8.27 in
- Motor Case Depth: Water Tap: 3.37 in | Dryer: 7.48 in
- ADA Compliance
Elegant All in One Touchless Washing Set
|
Gold Set
