Fontana HarmonyTrio Gold 3 in 1 Touchless Set – Soap, Water & Dryer
Fontana HarmonyTrio™ Gold 3 in 1 Automatic is the epitome of elegance, innovation, and convenience, featuring a touchless faucet, an automatic soap dispenser, and a high-speed dryer all in one seamless design. Constructed using premium brass and a sophisticated gold finish, this is a deck-mounted system durable with superior face to meet modern restroom aesthetics.
The touchless faucet operates with water pressure ranging from 0.05–0.6 MPA, and at an appealing 0.1–50°C temperature range, while the soap dispenser has a 1L capacity for high volume use with less replenishment. The high-speed dryer has a high-quality brushless 38,000 RPM motor generating airflow of 90m/s, blowing warm 30–40°C air, drying your hands in just 10–15 seconds – all while keeping the noise below 75dB. It has a HEPA filter to continuously purify air, and only uses 1W of power on standby. Compact shaped to exceed ADA specifications with dimensions of tap height 4.92 in, dispenser 4.92 in, and dryer 5.91 in, plus a precise size for the motor case is unmatched. The FontanaVeloraFlow is a high-end product that delivers a touchless option that embodies luxury, performance, and convenience in one stylish offering.
FontanaVeloraFlow™ Gold 3-in-1 Touchless Faucet, Soap Dispenser & Hand Dryer FAQ
38,000 RPM Brushless Drying, HEPA Filtration;
0.05–0.6 MPa Water Control & Gold Surface Protection
The FontanaVeloraFlow™ Gold 3-in-1 automatic system combines a touchless
water faucet, automatic soap dispenser, and high-speed hand dryer in a
coordinated deck-mounted configuration. It features premium brass construction,
0.05–0.6 MPa faucet operating pressure, 0.1–50 °C water-temperature operation,
a 1-liter soap reservoir, a 38,000 RPM brushless dryer motor, 90 m/s airflow,
HEPA filtration, and approximately 10–15 second hand-drying performance.
How should the faucet, soap dispenser, and dryer sensor zones be commissioned?
Complete commissioning after the basin, countertop, mirror, lighting,
partitions, and surrounding restroom accessories are fully installed.
Test the faucet, soap dispenser, and hand dryer independently from normal
user hand positions and confirm that each touchless function activates only
its intended component. Verify prompt faucet shutoff, controlled soap delivery,
and reliable dryer activation without cross-triggering between adjacent sensor
zones or unintended response from reflective countertop and basin surfaces.
How should the 0.05–0.6 MPa faucet pressure and 0.1–50 °C water range be verified?
Flush the water supply before final connection and verify that operating
pressure remains within the specified 0.05–0.6 MPa range while the faucet
is cycling. Confirm stable water delivery and temperature response throughout
the specified 0.1–50 °C operating range. If flow becomes weak or unstable,
inspect supply valves, hoses, inlet passages, filters, and the valve water
path for restrictions before diagnosing electronic sensor components.
What should be checked if drying takes longer than the specified 10–15 seconds?
Inspect the HEPA filter, air intake, dryer outlet, undercounter motor enclosure,
and connecting air path for accumulated dust or restriction. The dryer uses
a 38,000 RPM brushless motor producing approximately 90 m/s airflow and
30–40 °C drying air. A loaded filter, obstructed intake, restricted outlet,
loose air connection, or inadequate service-space ventilation can reduce
effective airflow even when the motor remains operational.
How should the Gold finish and undercounter components be maintained?
Clean exposed Gold brass surfaces with a soft damp microfiber cloth and dry
them after cleaning to reduce fingerprints, soap film, and water spotting.
Keep sensor windows, soap outlets, dryer air openings, and the HEPA intake
free from residue. Maintain accessible clearance around the 1-liter reservoir,
electrical controls, plumbing connections, and 1300W dryer assembly. Avoid
abrasive pads, acidic cleaners, bleach, ammonia, steel wool, and aggressive
metal polish that may damage the Gold finish.
Explore More
- Brand Name: FontanaShowers®
- Model Number: FS9902GL
- Finish: Gold
- Feature: Touchless Faucet, Soap Dispenser & Dryer (3-in-1)
- Material: Brass
- Installation Type: Deck Mount
- Voltage: 220–240V / DC6V (AC & DC Compatible)
- Frequency: 50Hz
- Total Power (Dryer): 1300W
- Standby Power: 1W
- Water Pressure (Faucet): 0.05–0.6 MPA
- Operating Temperature (Water): 0.1–50°C
- Soap Volume Capacity: 1L
- Dryer RPM: 38,000
- Hand Dryer Air Speed: 90 m/s
- Dryer Temperature: 30–40°C
- Noise Level: 75 dB
- Filter: HEPA
- Hand Dryer Dry Time: 10–15s
- Tap Height: Water Tap: 4.92 in | Dispenser: 4.92 in | Dryer: 5.91 in
- Tap Width: Water Tap: 1.97 in | Dispenser: 1.57 in | Dryer: 1.97 in
- Tap Depth: Water Tap: 6.69 in | Dispenser: 4.92 in | Dryer: 7.48 in
- Motor Case Height: Water Tap: 5.71 in | Dryer: 11.42 in
- Motor Case Width: Water Tap: 4.59 in | Dryer: 8.27 in
- Motor Case Depth: Water Tap: 3.37 in | Dryer: 7.48 in
- ADA Compliance
