Solo Oil Rubbed Bronze Touchless Motion Activated Sink Faucet and Soap Dispenser
|
Our Solo Oil Rubbed Bronze Sensor faucet is a brilliant solution for a specialty designed restroom being a simple 90-degree shape and charming Oil Rubbed Bronze color. Its built-in feature of a 30-second shut-off makes it more suitable for public restroom places. It is appreciated for both its beauty and triple-edged savings (water, energy and cost). Its intelligent design prevents water dripping. You will also minimize the waste of water, by using this automatic faucet. In any high-traffic restrooms avoiding contact with manual faucets helps avoid contact with germs that are collected on handles and this smart faucet is not only hygienic but will immediately reduce water waste by eliminating unnecessary and unattended water flow. The automatic faucet provides water only when needed. Additionally, since these faucets are preset to shut off after approximately 30 seconds, accidental flooding can't occur if a person leaves it running. And, because they are hands-free, they help reduce the spread of germs and keep the vanity area clean.
Touchless Motion Activated Sink Faucet Features
Fits all US standard plumbing. Uses 4AA Alkaline Batteries (purchase separately). Water Pressure: 0.5 - 7.0 KGS/cm, 10-125 psi.
- Motion detection touchless sensor faucet operation
- Commercial
- Sensitive Sensor with Infrared AI Smart-Chip
- Factory set to 30-second Auto Shutoff (can be adjusted).
- Water Pressure: 0.5 - 7.0 KGS/cm, 10 - 125 psi
- Solid Brass Construction, Oil Rubbed Bronze Finish
- Easy to Install - Instructions Included
- Water-resistant solenoid enclosure
- Advanced energy-saving design for long-lasting battery life
- Comes complete with Hoses & Accessories
- Power Supply: AC110V And DC6V (batteries not included)
- AC/DC power option.
- ADA Compliant.
- Can be installed easily in new or retrofit applications.
|

|
|
Intelligent: with its micro-computer controlling its action, the faucet can self-adjust its best detection zone as per the color and shape of the lavatory! The Sensor Faucet finish is Oil Rubbed Bronze, with a built-in Infrared AI Smart-Chip No Water Dripping Design with 100% Touch-free operation.
Reduces the transfer of germs by preventing cross-contamination and re-contamination of germs and bacteria by not touching the faucet handles. Cut down on water usage by minimizing waste of water by eliminating unnecessary or unattended water flow.
|
Solo Sensor Activated Faucet Special Features
- Durable Vandal-Resistant Brass Body; Ideal for commercial high use applications
- Intelligent: with its micro-computer controlling its action, the faucet will self-adjust its best detection zone as per the color and shape of the lavatory
- Flashing light indicator; a diagnostic indicator for power up, low battery, and solenoid function.
- The meanings of the codes are described in the installation instructions.
- Convenient to maintain; with a built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
- The faucet can be mounted to any sink surface.
- ADA Compliant.
- Batteries life is 8,000 cycles per month and with enough water pressure is the approx 5-year service life of the batteries.
- Adjustable sensing range; while the factory range is set about 4" to 5" from the sensor, it can be adjusted.
|
Diameter of the inlet pipe
|
DN15
|
|
Diameter of the outlet pipe
|
DN15
|
|
Faucet height
|
7.87" (200mm)
|
|
Spout Length
|
4.13" (105mm)
|
|
Water Pressure
|
0.05Mpa - 0.7Mpa
|
|
Power
|
DC.6V
|
|
Power Consumption
|
0.5MW
|
|
Detection Zone
|
Factory set 25cm/10" (based on standard inductive board)
|
|
Ambient Temperature
|
1 - 45 °C / 33.8 -113 °F
|
|
Degree of protection by enclosure
|
1P56
|
|
Battery
|
4 x 'AA' size cells
|
|
Operational water pressure range
|
0.05 - 0.6MPa
|
|
US standard water supply pipe size
|
DN15 (G1/2")
|
|
Ambient temperature range
|
0.1 - 45ºC
|
|
Sensing distance
|
9.84" (25cm)
|
|
Time delay
|
0.5 seconds
|
|
Operation duration
|
Power will automatically cut off after continuous use for 60 seconds
|
|
Pop-up drain
|
No
|
|
Color
|
Oil Rubbed Bronze Finish
|
Infrared sensor operated, touch-free operation
Advanced energy-saving design for long-lasting battery life
Waterproof sensor
Battery low LED light indicator
Sensing distance adjusted automatically
Long life durable body
Advanced circuit design saves electricity and water
For longevity of lifetime and to stand against daily wear and tear the Oil Rubbed Bronze finish used is PVD coatings
Sensor Faucet Advantage
Conserves water
Saves energy during the water heating process
Hygienic, no-touch activation
Easy installation
Durable, solid all-brass construction
Built-in filter
ADA compliant Ideal for use by disabled people
Vandal resistant
Waterproof Components
Sensor Faucet water-saving; hygienic; automatically opens and closes
to free hands - no touch, avoid bacteria mutual infections!
A great addition to powder room; kids bathroom!
This Sensor Faucet Applications; Residential, Commercial use & ADA
- This faucet is shipped complete. ANSI A112.18.1M
CSA Standard B125, 2.2 U.S.
- GPM Complies with NSF Standard 61, Section 9
- Flow Preventers Stainless Steel Hoses Mounting Hardware Batteries Pre-installed All the hardware necessary for satisfactory installation
Specifications and Dimensions
|
Spout
|
Chrome Plated Solid Brass
|
|
Power
|
4 (AA) Alkaline Batteries or AC Adapter
|
|
Battery life expectancy
|
250,000 cycles
|
|
Solenoid valve
|
6 Volt magnet latching
|
|
Working Water Pressure
|
1 PSI -100 PSI
|
|
Supply Inlet Size
|
1/2” NPT Male
|
|
Water Temperature Control
|
Built-in
Pop-Up Drain
|
|
Sensor type and Location
|
Active Infrared, Neck mount Sensor
|
|
Microprocessor
|
Digital, Pug And Play
|
|
Sensing Range
|
2” to 6”
|
|
Response Time
|
0.3 Second
|
|
Shut-Off Delay Time
|
2 Seconds
|
|
Anti vandalism maximum Running Time
|
60 Seconds
|
|
Particle filter size
|
50
|
|
Mesh Aerator
|
2.2 GPM Standard
|
|
|
 |
 |
 |
 |

|
