FontanaAquaZenith Sensor Automatic Bathroom Faucet in Rose Gold
Engineered as a motion-activated water delivery assembly with sealed electronics, heavy-duty solenoid valve, and replaceable service modules to sustain performance under continuous high-traffic use. This contemporary touchless faucet from FontanaAquaZenith™ in rose gold adds a modern touch to the commercial restroom environment while improving hygiene, increasing efficiency in your restroom, and adding impermeable beauty that complements your architecture.
It is engineered from durable brass with a polished rose gold finish for strength and is a luxurious touch to a modern space. With an intelligent infrared sensor and a detection distance of 18±2 cm, the touch-free tap will enhance hygiene by enabling hands-free operation to reduce any touch points and will minimise cross-contamination. The faucet is designed to be deck-mounted, so it will need one hole drilled in the mounting surface, and it can accept both an AC220V or DC6V supply for flexibility during installation. This emphasises performance while providing a steady flow, and saves as much as 50% water during usage. It is capable of accepting pressures from 0.05–0.7 MPa and successfully completed its over-pressure testing at 12 KG/m. The faucet is IP65 rated to protect the inner workings from the splash of water and to help give it a life of +500,000 cycles. It will be integrated into the layout of your modern restroom, measuring only 6.30" × 6.30" × 5.12", and it is designed to be ADA-compliant for accessibility. The FontanaAquaZenith™ is a fine combination of luxury, technology, and practicality.
FontanaAquaZenith™ Rose Gold Dual Sensor Automatic Faucet FAQ
Dual-Sensor Calibration, IP65 Valve Protection; Rose Gold Surface Care
The FontanaAquaZenith™ Rose Gold automatic faucet combines solid-brass construction, adjustable dual-sensor activation, single-hole deck mounting, AC220V or DC6V power, IP65 waterproof protection, and reliable operation across a 0.05–0.7 MPa water-pressure range.
How should the adjustable 18 ± 2 cm sensor range be commissioned?
Complete sensor adjustment after the basin, backsplash, mirror, soap dispenser, lighting, and countertop accessories are installed. Test both detection points from normal hand-entry positions and reduce the sensing distance if reflective surfaces, nearby movement, or the basin itself causes unintended activation.
What should be checked if the two sensors respond at different distances?
Clean both infrared sensor windows, confirm that the faucet body is securely mounted, verify stable AC220V or DC6V power, and inspect the electrical connections. Reflective objects, surface contamination, misalignment, or changing ambient light can affect either sensor’s effective detection range.
How should the faucet be tested across its 0.05–0.7 MPa operating range?
Flush the supply line before connection, inspect the inlet filter, and test activation under dynamic water pressure. Confirm stable discharge, immediate sensor response, and complete valve closure after hand removal while checking all connections for leakage or pressure-related movement.
How should the polished Rose Gold finish be cleaned without discoloring it?
Remove fingerprints, soap residue, and water spots with a soft damp microfiber cloth, then dry the faucet immediately. Use diluted pH-neutral soap only and avoid abrasive pads, acidic descalers, bleach, ammonia, steel wool, polishing powders, metal polish, and concentrated disinfectants.
Read More
- Brand Name: FontanaShowers®
- Model Number: FS7960RG
- Finish: Rose Gold
- Style: Contemporary
- Type: Touchless Bathroom Faucet
- Material: Brass
- Installation Type: Deck Mounted
- Number of Holes for Installation: One Hole
- Sensor Distance: 18±2cm(Adjustable)
- Power Input: AC220V & DC6V
- Sensor Type: Touchless
- Features: Electric Faucets, Metered Faucets, Sense Faucets
- Faucet Mount: Single Hole
- Application: Commercial Bathroom
- Installing Hole: 1"(25 mm)
- Water Saving: 50%
- Water Pressure: 0.05–0.7 MPa
- Over-Pressure Testing: 12 KG/m
- Waterproof: IP65
- Faucet Lifetime: ≥ 500,000 times
- Faucet Size: 6.30" × 6.30" × 5.12" (160 × 160 × 130 mm)
- ADA Compliant
