Fontana Leo™ Brushed Gold Commercial Automatic Touchless Sensor Faucet FAQ
Infrared Touchless Activation, 0.05–0.8 MPa Operation;
6.69" Faucet Height & Brushed Gold Protection
The Fontana Leo™ Brushed Gold Sensor Faucet combines brass construction,
automatic sensing, single-hole mounting, and commercial-grade water control.
How should the infrared sensor be commissioned after installation?
Complete commissioning after the basin, countertop, mirror, lighting,
and surrounding accessories are installed. Test repeated hand-entry
and withdrawal cycles and confirm reliable activation followed by
complete automatic shutoff. Check reflective surfaces for unintended
sensor triggering before final handover.
How should the 0.05–0.8 MPa operating pressure be checked?
Flush the supply piping before final connection and verify operating
pressure within the specified 0.05–0.8 MPa range. Perform repeated
sensor cycles and confirm stable discharge. If flow becomes restricted,
inspect the supply path and outlet before servicing the electronic
sensor components.
How should the 4.92-inch spout length be coordinated with the basin?
Establish the single-hole mounting centerline against the actual basin
before final tightening. The faucet is approximately 6.69 inches high
with a 4.92-inch spout length and 3.93-inch spout height. Confirm that
discharge lands within the primary washing zone while maintaining
adequate hand clearance and splash control.
How should the Brushed Gold finish and sensor area be maintained?
Clean exposed surfaces with a soft damp microfiber cloth and dry them
afterward. Keep the sensor area and outlet free from soap film and
mineral deposits. Avoid abrasive pads, steel wool, acidic cleaners,
bleach, ammonia, and aggressive polishing compounds.
