Fontana Trialo Color Changing LED Shower Head with Adjustable Body Jets
The Trialo Rainfall Shower Set from FontanaShowers is one of the most customizable models available. You can adjust almost any feature to best suits your needs. The shower head is available in round or square design and varies in size from 8” to 24”. The standard mixer comes with the set but can be upgraded to a thermostatic mixer. Six adjustable body massage jets and a handheld shower for your convenience. It comes complete with accessories and installation instructions.
Fontana Trialo Color Changing LED Shower Head with Adjustable Body Jets Features:
|
Brand Name: FontanaShowers
Model Number: LED-SHOWER-HEAD-0522GN
Type: Shower Set
Material: Solid Brass
Finish: Brushed Nickel
Style: Contemporary Rain Showerhead
Showerhead Thickness: 0.33"
Showerhead Width: Available in 8", 10", 12", or 16"
Showerhead Length: Available in 8", 10", 12", or 16"
LED Power Source: Water Flow
LED Colors: Blue, Green, Red
Showerhead Style: Contemporary Rain Shower
Mount Method: Wall or Ceiling Mount
Connection: 1/2" US standard (included)
Shower Arm: Included
Body Jets: Solid Brass
|
|
FontanaShowers®Product Warranty Information
- efore you begin, please read the installation instructions below. Observe all local building and safety codes.
- Unpack and inspect the product for any shipping damages. If you find damages, do not install.
- Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided.
|
-------
|
-----
|
|
Shower Head Installation Instructions
|
|
|
|
|
|
|
|
Step 1:
|
shower
|
Step 2:
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Step 3:
|
|
Step 4:
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Step 5:
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1. Apply plumber's tape to the threads on both ends of the shower arm and slide on the decorative escutcheon.
2. Insert the new arm into the fitting in the ceiling and twist to tighten. Finish tightening with your adjustable wrench. Wrap a dry cloth around the shower arm to protect the finish while tightening with adjustable wrench.
3. Thread the new shower head onto the arm and hand-tighten. Hold the shower arm in place with groove joint pliers and finish tightening the shower head with your adjustable wrench. Wrap both in a dry cloth to protect the finish.
4. Before securing the decorative escutcheon, turn on the water supply to make sure that all connections are tight and there is no leaking. If no leaks are detected, continue with the installation. If leakage does occur, use your adjustable wrench to tighten the connections as necessary.
5. Apply a bead if silicone sealant to the back of the escutcheon and press firmly into place against the installation surface. Wipe away any excess sealant with your damp cloth.
|
|
|
|
Hand Held Shower Installation Instructions
|
Step 1:
|
hand shower
|
Step 2:
|
|
|
|
|
|
HAND
HELD
SHOWER
|
|
|
|
|
|
|
|
Step 3:
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Hand Shower Outlet Installation
• Complete the outlet pipework ensuring it ends in an appropriate 15mm x 1/2" BSP female thread elbow.
Note:
This fitting is not supplied as variations in installations require the selection of a suitable solder or compression fitting.
• Install the 'Wall Outlet', thread long male 1/2" BSP into the appropriate female fitting using PTFE tape to give a watertight joint.
Note: The thread can be cut to size if required. Make sure that all debris is removed from the connector and the section that has been cut is dressed correctly, before installation.
Shower Wall Holder Installation
Decide the position for the shower head holder on the wall within the bath showering area and proceed as follows:
• Hold the hand shower head holder fixing plate in a suitable position on the wall, mark out the position of the holder. Mark the two locating holes, these are 17mm center.
• Drill and plug the wall. Use an appropriate masonary drill, but if the wall is plasterboard or a soft building block, use special wall plugs and an appropriate drill bit.
• Slide the inserts onto the screws in the orientation. Secure the inserts by tightening the screws.
• Slide the hand shower head holder body onto the inserts and secure by tightening the grub screw facing down.
|
|
|
|
|
|
|
|
|
|
Shower Body Jets Installation Instructions
|
|
|
