Spec-Ready Design™ Commercial Touchless Faucets

A specification-ready faucet should have an identifiable manufacturer, model number, configuration, finish code, dimensional drawing, installation instructions, and documented operating parameters. Engineering review should include rated flow, allowable supply pressure, connection sizes, sensor detection characteristics, electrical requirements, and serviceable components. Where applicable, submittals should identify conformity with ASME A112.18.1/CSA B125.1, NSF/ANSI/CAN 61 and 372, and project-specific accessibility requirements. Claims of certification or compliance must be supported by documentation for the exact model and configuration.

Wall-mounted sensor faucets require coordinated rough-in elevations, spout projection, finished-wall thickness, basin positioning, and water-supply connections. Engineers should verify that the discharge stream reaches the intended basin receiving area without excessive splash or interference with the drain assembly. Sensor detection zones must be evaluated against basin reflectivity, mounting height, and surrounding surfaces. Concealed valve assemblies, power connections, and service components should remain accessible through the manufacturer-approved maintenance arrangement. Final installation dimensions must follow the specific product submittal rather than nominal architectural elevations.

Finish coordination should be controlled through an approved fixture schedule identifying each faucet's manufacturer, model, finish code, substrate, and documented surface treatment. Chrome, brushed nickel, matte black, gold, rose gold, gun metal gray, and oil rubbed bronze are represented within the collection, but availability and finish construction vary by model. Specification teams should obtain manufacturer finish samples where visual consistency is critical and verify cleaning compatibility, environmental exposure limitations, and maintenance instructions. Similar marketing finish names should not be assumed to represent identical materials, coatings, or performance characteristics.

Yes. A performance-based specification can establish common requirements for automatic activation, flow control, water-supply compatibility, installation quality, electrical safety, maintenance access, and documented product conformity while permitting different architectural profiles. Traditional Antique Edition models and contemporary sensor faucets can be scheduled under the same performance framework when each proposed model independently satisfies the applicable criteria. Designers should separately verify mounting configuration, spout reach, sensor location, flow rate, mixing arrangement, power source, and replacement-part availability. Visual similarity or shared manufacturer branding does not establish technical interchangeability.

Engineering review should confirm the sensing technology, nominal detection range, activation and shutoff behavior, adjustable settings, and susceptibility to unintended triggering from reflective surfaces or adjacent fixtures. Electrical coordination should identify whether the selected model operates through batteries, a manufacturer-approved AC adapter, or an AC/DC arrangement. Verify rated voltage, current requirements, power-supply location, cable routing, connector protection, and applicable electrical listings. Solenoid accessibility and any defined fail-safe or power-loss behavior should also be documented. Sensor range, operating voltage, and timing settings must be obtained from the exact model's technical documentation rather than assumed across the product series.

A coordinated approval package should include current product data sheets, dimensioned installation drawings, plumbing connection requirements, flow and operating-pressure information, electrical schematics where applicable, installation instructions, finish identification, and maintenance documentation. Where available, request BIM/Revit families containing accurate geometry, connection locations, mounting references, and product identification parameters. Engineers should compare submitted data with the fixture schedule, plumbing drawings, electrical provisions, and project specification requirements. BIM geometry is a coordination resource and should not replace verified manufacturer dimensions or formally approved technical submittals.

Verify manufacturer-rated flow at the specified test pressure, acceptable operating-pressure range, supply connection dimensions, and compatibility with the proposed mixing and temperature-control arrangement. Coordinate spout reach, outlet height, basin geometry, sensor detection location, and maintenance clearances using actual construction dimensions. For accessible installations, evaluate the complete lavatory assembly against the applicable provisions of the 2010 ADA Standards and ICC A117.1 as adopted by the project jurisdiction. Where required, also verify applicable temperature-limiting provisions, including ASSE 1070, based on the selected device and installation. Compliance must be assessed for the installed assembly rather than inferred from the faucet designation alone.

Commissioning should confirm proper mounting, secure supply connections, leak-free operation, correct electrical or battery installation, and reliable solenoid response. Technicians should test sensor activation across the intended user approach range, verify automatic shutoff, observe basin discharge for splashing, and check for unintended activation from nearby surfaces. Measure flow and supply pressure where required by the approved project documents, and verify mixed-water delivery temperature against the specified temperature-control strategy. Complete maintenance-access checks, clean inlet filters where directed, and record model identification, approved settings, test observations, and corrective actions. Final acceptance should be based on manufacturer instructions and project-specific commissioning criteria.
