Bravat Commercial Automatic Motion Dark Oil Rubbed Bronze Sensor Faucets with Automatic Soap Dispenser
Bravat Commercial Automatic Motion Dark Oil Rubbed Bronze Sensor Faucets with Automatic Soap Dispenser



Alternative Views:


Retail Price: $1,514.38
Sale Price: $1,388.18
Savings: $126.20

Price with Selected Options: $1,388.18






Availability: Usually Ships in 5 to 10 Business Days
Product Code:
FS10206DORB


Hot & Cold Option:


Qty:
Description Technical Specs Extended Information


Bravat Commercial Automatic Motion Dark Oil Rubbed Bronze Sensor Faucets with Automatic Soap Dispenser

Bravat Commercial Automatic Aqua Motion Sensor Faucets

Bravat Motion Sensor Faucet Specifications

Diameter of inlet pipe DN15
Diameter of the outlet pipe DN15
Water Pressure 0.05Mpa - 0.7Mpa
Power and Voltage DC.6V / AC.110-220V - 50/60Hz
Power Consumption 0.5MW
Detection Zone Factory set 25cm/10" (based on standard inductive board)
Ambient Temperature 1 - 45 °C / 33.8 -113 °F
Degree of protection by enclosure 1P56
Battery 4 x 'AA' size cells
Operational water pressure range 0.05 - 0.6MPa
Water supply pipe size DN15

Sensor Activated Faucet Special Features

  • Durable Vandal-Resistant Brass Body; Ideal for Residential as well as commercial high use applications
  • Intelligent: with its micro-computer controlling its action, the faucet will self adjust its best detection zone as per the color and shape of lavatory
  • Flashing light indicator; a diagnostic indicator for power-up, low battery, and solenoid function.
  • The meaning of the codes are described in the installation instructions.
  • Convenient to maintain; with a built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
  • Faucet can be mount to any sink surface.
  • ADA Compliant.
  • Batteries life 8,000 cycles per month and with enough water pressure is approx 5-year service life of the batteries.
  • Adjustable sensing range; while the factory range is set about 4" to 5" from the sensor, it can be adjusted.

Features


The Bravat Sensor Activated Touchless Faucet

    • Sensor faucet complete motion detection operation.
    • Sensitive Sensor with Infrared AI Smart-Chip
    • Factory set to 30-second Auto Shutoff (can be adjusted).
    • Water Pressure: 0.5 - 7.0 KGS/cm , 10 - 125 psi
    • Solid Brass Construction, Dark Oil Rubbed Bronze Finish
    • Easy to Install - Instructions Included
    • Water-resistant solenoid enclosure
    • Advanced energy-saving design for long-lasting battery life
    • Comes complete with Hoses & Accessories
    • Power Supply: AC110V And DC6V (batteries not included)
    • AC/DC power option.
    • ADA Compliant
    • Easily can be installed in new or retrofit applications.
    • Usage: Commercial / Residential
