Fontana Bolln Gun Metal Gray Single Function Universal Rain Round Shower Head
Fontana Bolln Gun Metal Gray Single Function Universal Rain Round Shower Head

Alternative Views:



Availability: Project Pricing Available Request Quote
Product Code: FS-15073SH-GMG
Request Quote

Description Technical Specs Extended Information


Chrome

Brushed Nickel

Gold

Brushed Gold

Rose Gold

Venetian Bronze

Champagne

Matte White

Matte Black

Fontana Bolln Gun Metal Gray Single Function Universal Rain Round Shower Head

Created with a touch of modern sophistication, the FontanaBolln Gun Metal Gray Shower is sure to decorate your bath. Striking a gun metal gray finish, the Glo Shower Head enhances the industrial and sophisticated look of your bathroom, creating a sleek and contemporary look. Engineered from high-grade metal, it ensures durability and long-lasting operation, hence a safe bet in any bath upgrade. Its 11-3/4" round head offers a soothing, full-body shower experience with its big rain spray pattern. The single-function spray gives a flow of 2.5 GPM, exactly right to deliver comfortable water pressure without overwhelming the senses of a shower.A user-friendly product, the showerhead connects straight into standard U.S. plumbing connections. They also come in Revit Families and B.I.M. Objects, which provides some flexibility for architects and designers working on different projects.As the perfect blend of modern design and solid construction, the Fontana Bolln Gun Metal Gray Shower Head is a big plus when it comes to accessorizing any modern bathroom.A separate purchase would be required for the shower arm and flange, should you want one. Bold statement piece for your bathroom, a really good and hardy shower head.


Fontana Bolln Gun Metal Gray Single Function Universal Rain Round Shower Head Features:

  • Brand Name: FontanaShowers®
  • Model Number: FS-15073SH-GMG
  • Type: Shower Head
  • Style: Contemporary
  • Shower Head Width: 11-3/4" (left to right)
  • Flow Rate (GPM): 2.5 gallons-per-minute
  • Shower Arm Included: No
  • Faucet Type: Shower Faucet
  • Material: Metal
  • Showerhead: Single Function
  • Shower Head Shape: Round
  • Spray Pattern: Rain
  • Spray Settings: 1
  • Water Efficient: No
  • Spec: Shower Head available in Revit Families, and BIM Object
  • Finish: Gun Metal Gray

Features


Fontana Bolln Gun Metal Gray Rain Shower Head FAQ

2.5 GPM Testing, Swivel Alignment & Round Rainfall Spray Commissioning

This gun metal gray round shower head combines durable metal construction, an 11-3/4-inch rainfall spray face, single-function 2.5 GPM discharge, and a standard threaded inlet for contemporary residential, hospitality, and specification-driven shower projects.

How should the shower supply branch be flushed before installation?
Remove the finished shower head and flush the shower-arm branch until pipe scale, solder residue, construction debris, and excess thread-sealing compound are fully discharged. Inspect the threaded outlet before connecting the finished gun metal gray fixture.
How should the swivel inlet and round spray face be aligned?
Confirm that the shower arm projects squarely without lateral loading. Seal the threaded joint sparingly, adjust the swivel until the 11-3/4-inch spray face is level, and avoid transferring excessive tightening torque through the finished metal body.
How should the specified 2.5 GPM discharge be field-verified?
Stabilize the dynamic supply pressure, purge entrained air, and perform a timed volumetric test at the shower head. Reduced delivery may indicate branch-line pressure loss, construction debris, mineral restriction, or blockage within the internal flow passage.
What confirms correct rainfall spray-face commissioning?
Verify uniform water distribution across the complete 11-3/4-inch nozzle field without inactive outlets, weak perimeter zones, pulsing, lateral jetting, or irregular droplet formation. Uneven coverage normally requires additional flushing or nozzle cleaning.
