Fontana Bolln Matte White Single Function Universal Rain Round Shower Head

Place the Fontana Bolln Matte White Shower head onto your bathroom to reveal modern elegance. Positioned for people who find both functionality and forms desirable, this shower head is defined by the matte white finish lending itself to the contemporary designs. Made of high-end metal to guarantee that you have long life and sound performance even when in the line of fire of frequent use. The 11-3/4" round head produces a rain spray pattern for a soft, full-body shower experience. The single-function spray has a 2.5 GPM flow rate, the perfect amount of water pressure for a refreshing, invigorating shower, every time. This is plumbing, designed to fit, and made it easily accessible into standard U.S. plumbing connections. Requires separate purchase of shower arm and flange to allow a more customized installation. Being available as Revit Families and BIM Objects makes this an excellent choice for architects and designers. The Fontana Bolln Matte White Shower Head delights your eyes while ensuring high performance. Ideal for modern bathrooms, it stands for a perfect combination of style, function, and reliability.


Fontana Bolln Matte White Single Function Universal Rain Round Shower Head Features:

  • Brand Name: FontanaShowers®
  • Model Number: FS-15073SH-MW
  • Type: Shower Head
  • Style: Contemporary
  • Shower Head Width: 11-3/4" (left to right)
  • Flow Rate (GPM): 2.5 gallons-per-minute
  • Shower Arm Included: No
  • Faucet Type: Shower Faucet
  • Material: Metal
  • Showerhead: Single Function
  • Shower Head Shape: Round
  • Spray Pattern: Rain
  • Spray Settings: 1
  • Water Efficient: No
  • Spec: Shower Head available in Revit Families, and BIM Object
  • Finish: Matte White

Features


Fontana Bolln Matte White Rain Shower Head FAQ

2.5 GPM Testing, Swivel Alignment & Rainfall Nozzle Commissioning

This matte white round shower head combines durable metal construction, an 11-3/4-inch rainfall spray face, single-function 2.5 GPM discharge, and a standard threaded inlet for contemporary residential, hospitality, and specification-driven shower projects.

How should the shower-arm branch be flushed before installation?
Remove the finished shower head and flush the open shower-arm connection until pipe scale, solder residue, construction debris, and excess thread-sealing material are fully discharged. Inspect the threaded outlet before attaching the finished matte white fixture.
How should the swivel connection and round spray face be aligned?
Confirm that the shower arm projects squarely without lateral loading. Seal the threaded joint sparingly, adjust the swivel until the 11-3/4-inch spray face is level, and avoid applying tightening torque through the matte white outer body.
How should the specified 2.5 GPM discharge be field-verified?
Stabilize the dynamic supply pressure, purge entrained air, and perform a timed volumetric test at the shower head. Reduced delivery can indicate branch-line pressure loss, construction debris, mineral restriction, or blockage within the internal flow passage.
What confirms correct rainfall nozzle-field commissioning?
Verify uniform discharge across the complete 11-3/4-inch spray field without inactive outlets, weak perimeter zones, pulsing, lateral jetting, or irregular droplet formation. Uneven coverage normally requires additional flushing or nozzle cleaning.
