Fontana Brushed Gold Tone Plated Platinum Commercial Thermostatic Automatic Sensor Tap Solid Brass Construction
Gold Tone Plated Platinum Commercial Thermostatic Automatic Sensor Tap Solid Brass Construction



Alternative Views:
Retail Price: $613.25
Sale Price: $516.16
Savings: $97.09

Price with Selected Options: $516.16





Availability: Usually Ships in 5 to 10 Business Days
Product Code: FS-505G


Hot & Cold Option:

Qty:
Description Extended Information

BIM Model Object File Specification Sheet Specification Sheet
Installation Instructions Installation Instructions Repair & Maintenance Guide
 Product Detail Brochure 3D Product Rendering
Installation Detail Video Installation Detail Video FontanaShowers® Product Warranty 5-Year Product Warranty Sheet

Platinum Commercial Automatic Touchless Sensor Faucet Gold Tone Finish (Hot & cold)

The Platinum Sensor Faucet electronically controlled faucets that eliminate the need to touch or turn handles. Through the use of sensor beams, the automatic faucet determines when an object is in front of it and automatically turns on the faucet. Since there is nothing to touch and nothing to reach for, an automatic faucet eliminates all of that cleaning and disinfecting that you do to try to maintain a hygienic surface. Bathroom sensor faucets are anti-erosion, anti-abrasion and high strength. Intelligent: with its micro-computer controlling its action, the faucet can self adjust its best detection zone as per the color and shape of lavatory! Sensor Faucet finish is Gold Tone, with built-in Infrared AI Smart-Chip No Water Dripping Design 100% Touch-free operation. Minimize waste of water, by using the automatic faucet. Immediately reduces water waste by eliminating unnecessary and unattended water flow. Fits all standard US plumbing.

Platinum Infrared Motion Sensor Faucet Specification:

  • Brand Name: FontanaShowers®
  • Model Number: FS-505G
  • Finish: Gold
  • Installation Type: Deck Mount
  • Hot and Cold Water: Optional
  • Type: Automatic Faucet
  • Valve Type: Solenoid valve
  • Material: Brass
  • Power Supply: AC 110V and DC 6V
  • Overall Height: 7"
  • Spout Height: 4.6"
  • Spout Reach: 2.8"
  • Mounting Type: Single hole
  • Number of Holes: Required for Installation: 1
  • Faucet Centers (Distance Between Handle Installation Holes): Single Hole
  • Flow Rate: 1.3 GPM (gallons-per-minute)
  • Maximum Deck Thickness: 1-5/8"
  • ADA Compliant
  • Infrared sensor operation with temperature control.


automatic-faucet-diagram automatic-faucet-rohos automatic-faucet-ceimages

Features


Commercial Automatic Touchless Sensor Faucet Gold Tone Finish Feature :

  • Uses 4AA Alkaline Batteries (purchase separately).
  • Water Pressure: 0.5 - 7.0 KGS/cm, 10-125 psi.
  • Touchless Operation
  • Sensitive Sensor with Infrared AI Smart-Chip
  • Factory set to 30-second Auto Shutoff
  • Water Pressure: 0.5 - 7.0 KGS/cm , 10 - 125 psi
  • Solid Brass Construction, Gold tone Finish
  • Easy to Install - Instructions Included
  • Water resistant solenoid enclosure
  • Advanced energy saving design for long lasting battery life
  • Comes complete with Hoses & Accessories
  • Easily can be installed in new or retrofit applications
  • Usage: Commercial / Residential
  • Ideal for commercial use applications in public restrooms, restaurants, office building, public facilities, hospitals. Fits all standard US plumbing.
  • Durable Vandal-Resistant Brass Body; Ideal for Residential as well as commercial high use applications
  • Intelligent: with its micro-computer controlling its action, the faucet will self adjust its best detection zone as per the color and shape of lavatory
  • Flashing light indicator; a diagnostic indicators for power up, low battery, and solenoid function.
  • Meaning of the codes are described in the installation instructions.
  • Convenient to maintain; with built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
  • Faucet can be mount to any sink surface.
  • Batteries life 8,000 cycles per month and with enough water pressure is approx 5 year service life of the batteries.
  • Adjustable sensing range; while the factory range is set about 4"to 5"from the sensor, it can be adjusted.
  • Diameter of inlet pipe DN15
  • Diameter of outlet pipeDN15
  • Water Flow Rate: 1.3 GPM (gallons-per-minute)
  • Power DC.6V
  • Detection Zone Factory set 25cm/10" (based on standard inductive board)
  • Ambient Temperature 1 - 45 ℃ / 33.8 -113 °
  • Degree of protection by enclosure 1P56

Platinium Infrared Motion Faucet Features :

  • The infrared sensor technology: Sensor-operated taps increase hygiene in public and patient restrooms. Surprisingly, the dirtiest area in the bathroom, as far as germs are concerned, are the handles to the tap that collect most of the germs on them.
  • The thermostatic technology: Controlling the temperature fluctuations atthe outlet prevents scalding. Mixing the water at the desirable temperature at the point of use allows to store the water enoughcoldand hot to prevent scalding.
  • Installation is a child's game, almost like a manual faucet
  • Easy servicing
  • Version with mixer to adjust the temperature.
  • The Gold finish will not fade, tarnish or corrode for the lifetime of the faucet.
  • 6V battery or electrical connection version available
  • Solenoid valve inside the product
  • Operates with low and high pressures (0.5 to 7Bar)
  • Range adjustment
  • Two products in 1: the thermostatic mixing valve and operates by an infrared sensor
