FontanaAeroFusion Oil Rubbed Bronze 3-in-1 Touchless Soap Dispenser, Water Tap & Hand Dryer
The Fine-Luxury 3-IN-1 style fixture by FontanaAeroFusion™ elevates hygiene experiences in every bathroom. Automatic soap dispenser, sensor-operated faucet, and hand dryer in a wall mount form provide the neatest configuration possible so that the area does not look cluttered and hygienic. Oil-rubbed bronze, being a warm finish, offers rustic charm for interiors that lean either on the traditional or industrial side and a tad bit polished.
Being polished stainless steel with a ceramic valve core, the units promise resistance against the ragging use and operational longevity. The intelligent sensor activation allowed full touchless operation, thereby improving sanitation and user convenience. Drying time is great at 70 dB noise levels, where the air speed of 95 m/s from the hand dryer offers rapid drying but allows comfort. The HEPA filtration conveniently purifies the air, thereby promoting a healthier restroom environment. Aptly offering a fountain and soap dispenser compatible with liquid or foam and with options for brushless or brush motor, this dispenser is highly flexible in catering to different needs and thereby, suitable for top-tier commercial environments.
FontanaAeroFusion™ Oil Rubbed Bronze 3-in-1 Touchless Hygiene System FAQ
HEPA Airflow Verification, Sensor Synchronization; Oil Rubbed Bronze Surface Protection
The FontanaAeroFusion™ Oil Rubbed Bronze 3-in-1 hygiene station integrates a touchless faucet, automatic soap dispenser, and high-speed hand dryer into a wall-mounted stainless steel assembly featuring a ceramic valve, 1 L reservoir, HEPA filtration, and 95 m/s drying performance for demanding commercial washrooms.
How should the faucet, soap dispenser, and dryer sensors be commissioned after installation?
Complete calibration after the basin, mirror, backsplash, and surrounding accessories are fully installed. Test each sensor independently to verify that the soap dispenser, faucet, and dryer activate only within their intended operating zones without interference from adjacent fixtures or reflective surfaces.
What should be inspected if the hand dryer no longer reaches its specified drying performance?
Inspect the HEPA filter, motor intake, outlet nozzle, and internal airflow passages for blockage. Reduced air velocity may also result from unstable electrical supply, restricted ventilation around the motor housing, or accumulated debris that limits the designed 95 m/s airflow performance.
How should the water system be commissioned before normal operation?
Flush the G1/2-inch supply line thoroughly before connecting the faucet assembly to remove solder residue, pipe scale, and thread sealant. Verify stable operating pressure between 1 and 6 bar while checking the ceramic valve, sensor activation, and complete faucet shutoff after each operating cycle.
How should the Oil Rubbed Bronze finish be maintained in high-traffic commercial facilities?
Clean exposed surfaces with a soft microfiber cloth and diluted pH-neutral soap, then dry immediately to minimize water spotting. Avoid abrasive pads, acidic descalers, bleach, ammonia, polishing compounds, steel wool, and concentrated disinfectants that may damage the protective bronze finish.
Read More
- Brand Name: FontanaShowers®
- Model Number: FS10506ORB
- Style: Modern Simplicity
- Type: Touchless Basin Faucet
- Material: Stainless Steel
- Finish: Oil Rubbed Bronze
- Number of Holes for Installation: Three Hole
- Features: Electric Faucets, Sense Faucets
- Function: Soap Dispenser, Faucet, Hand Dryer
- Installation Type: Wall Mounted
- Valve Core Material: Ceramic
- Surface Treatment: Polished
- OEM and ODM: Highly Welcomed
- Capacity: 1 L
- Dispenser Type: Available with Liquid or Foam Outlets
- Inlet Connection: G1 /2"
- Operating Water Pressure: 1 - 6 bar
- Available with Brushless or Brush Motor: Yes
- Filter Type: HEPA
- Air Speed: 95m/s
- Noise Level at 2m: 70db
- Application: Hotel, Apartment, Bathroom
