FontanaAuraAir Oil Rubbed Bronze Wall Mounted Smart Touch Free Dryer
Rich and filled with character, the FontanaAuraAir™ Oil Rubbed Bronze Hand Dryer exudes timeless appeal in touching advanced touchless technology for classy restrooms. Dark bronze finish introduces a classic accent with which sophistication and durability combine to high-end interiors. Crafted in strong brass with a polished surface treatment, rendering it resistant while carrying on with a very elegant visage. Wall-mounting saves space, rapid drying occurs in a mere 10-15 seconds, thanks to a high-speed brushless motor running at 38,000 RPM with an air speed of 90m/s. Dryers are controlled from 30 to 40 degrees Celsius, resulting in user comfort and good energy consumption. It consumes 1 W and produces noise at an average loud 75 dB, perfect for drying, accompanied by efficiency and user comfort. A HEPA filtration system is fitted inside, delivering better clean air, and comes further with an IP24 waterproof rating specifying reliability in demanding conditions. Strength, hygiene, elegance-to merge these three concepts in one generation, and that is how they give a redefined professional drying solution with a touch of practicality and prestige.
Classic Bronze, Modern Hygiene
- Brand Name: FontanaShowers®
- Model Number: FS10509ORB
- Type: Touchless Hand Dryer
- Style: Contemporary
- Finish: Oil Rubbed Bronze
- Mount Type: Undercounter
- Installatron Type: Deck Mounted
- Main Material: Brass
- Surface Treatment: Polished
- Motor: Brushless
- Voltage: 220-240 V
- Frequency: 50Hz
- Total Power: 1300W
- Standby Power: 1W
- RPM: 38000
- Air Speed: 90m/s
- Temperature: 30-40degrees
- Noise Level: 75dB
- Waterproof: IP24
- Filter: HEPA
- Dry Time: 310-15s
- Tap Height: 170mm
- Tap Width: 40mm
- Tap Depth: 223mm
- Motor Case Height: 290mm
- Moto Case Width: 210mm
- Motor Case Depth: 190mm
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
FontanaAuraAir™ Oil Rubbed Bronze Touchless Hand Dryer FAQ
HEPA Airflow Verification, Undercounter Ventilation; Oil Rubbed Bronze Surface Protection
The FontanaAuraAir™ Oil Rubbed Bronze touchless hand dryer combines a polished brass outlet, deck-mounted installation, an undercounter motor enclosure, a 38,000 RPM brushless motor, 90 m/s airflow, HEPA filtration, IP24 protection, and a rapid 10–15 second drying cycle.
How should the undercounter motor enclosure be positioned during installation?
Mount the motor case where its air intake, outlet connection, electrical supply, HEPA filter, and service panels remain accessible. Maintain clear ventilation around the enclosure and keep it away from plumbing connections where leakage could reach electrical components or restrict the designed airflow path.
What should be inspected if drying takes longer than the specified 10–15 seconds?
Inspect the HEPA filter, air intake, outlet passage, duct connection, and undercounter ventilation for restriction. A loaded filter, loose air connection, unstable 220–240V power, or obstructed motor housing can reduce the designed 90 m/s airflow and extend the drying cycle.
How should the 38,000 RPM brushless motor be evaluated during routine maintenance?
Verify immediate startup, stable airflow, consistent operating sound, and complete automatic shutdown after each cycle. Increased vibration, reduced air velocity, or unusual noise may indicate filter loading, restricted ventilation, loose mounting hardware, or debris within the motor and air-delivery path.
How should the Oil Rubbed Bronze finish be cleaned without changing its dark tone?
Remove fingerprints and water residue with a soft damp microfiber cloth, then dry the outlet immediately. Use diluted pH-neutral soap only and avoid abrasive pads, acidic cleaners, bleach, ammonia, steel wool, metal polish, and concentrated disinfectants that may brighten or discolor the bronze surface.
|
|
|
|
|
|
|
