How to install Alberni Gold PVD Solid Brass Mixer Bathroom Sink Faucet | FS-03187
Easy step by steps Installation Instructions for Faucet
Visit Product Page
Before you begin, please read the installation instructions below. Observe all local building and safety codes.
Unpack and inspect the products for any shipping damages. If you find damages, do not install.
Please note all products must be installed by a professional and certified plumber otherwise warranty might be voided.
faucet
Faucet Installations Instructions
Size
Deck Hole Size
faucet
Specs:
Faucet type: Bathroom Sink Faucet
Installation Type: Centerset
Installation Holes: One
Control Type: Single Lever
Finish: Ti-PVD
Style: Rustic
Range: 1.5 GPM (5.7 L/min)
Hot/Cold Water Switch: Yes
Valve Type: Ceramic Valve
Installation Holes and handles: single handle a hole
Total height: 180 mm (7.1)
Spout Height: 70 mm (2.8)
Spout Length: 125 mm (4.9)
Stainless Steel: Brass
Material of Body: Brass Tap
Step 1:
Step 2:
faucet
Step 3:
Step 4:
1. Remove the mounting nut, metal washer, and rubber washer from the threaded pipe. 2. Fit the O-ring into the groove of the faucet body. Screw waterlines into the corresponding screw-hole of the faucet body. 3. Insert waterlines and threaded pipe into the hole of the sink. 4. Install rubber washer, metal washer, and mounting nut back to the threaded pipe. Adjust the faucet body correctly and secure with mounting screws tightly. 5. Connect waterlines to angle stops. Turn on the angle stops and check for leaks (DO NOT TURN FAUCET ON). 6. Turn faucet on for 1 minute to flush any debris.
Important: Turn on hot and cold water supplies and flush water lines into a container for one minute. This flushes away any debris that could cause damage to internal parts.
Flexible Connecting Hose Care must be taken when connecting the flexible connection hose from the power supply box to the spout to ensure it does not bend sharply and kink or twist. See above for recommended ways to fit the flexible connecting hose.
Important: Failure to follow these guidelines may result in poor performance and damage to the flexible connection hose.
When it comes to new bathroom sink faucets, FontanaShowers is offering shape, finishes and styles that you've looking for. This has an elegant design and elevates the appeal of your decor made from the highest quality and for great tastes. It comes super seal technology inside, capable of delivering superior performance with a solid construction for long durability that will upgrade your bathroom with a modern and cool look for a long period of time. It is our goal to provide customer not only excellent products but also leading lifestyle.
