Inspired by nature and applied gracefully, the FontanaCorvane™ Swan Inspired Chrome Motion Sensor Faucet is a sculptural elegance and polished brilliance to elevate the restroom aesthetics. Whatever concept factories have done to capture the swan's gentle curves, it nonetheless offers an aristocratic competition point and affords effortless functionality through advanced touchless activation.
Commercially inclined for hygiene, as much as possible, to minimize fingerprint intrusion in water usage. Made of solid brass, the finish is chrome to guarantee strength and timelessness. Designed for single-hole deck mounting, the faucet can be installed smoothly on various projects. With a water pressure range of 0.05MPa-0.8MPa, the faucet is very reliable. Also, with a controlled flow rate of 1.58 GPM, the faucet conserves water without compromising comfort. Thus, ideal for luxury hotels and public spaces, the FontanaShowers blend seamlessly with the aesthetic of FontanaShowers, combining artistry and technology with enduring quality in today's sensor-activated bathrooms. Specified with sealed connectors and strain-relieved wiring to prevent fatigue in hardwired installations.
FontanaCorvane™ Chrome Swan-Inspired Touchless Faucet FAQ
Sensor Commissioning, 1.58 GPM Flow Stability; Chrome Surface Protection
The FontanaCorvane™ Chrome swan-inspired touchless faucet combines solid-brass construction,
single-hole deck mounting, motion-sensor activation, a controlled 1.58 GPM / 6 L/min flow rate,
and reliable operation across a 0.05–0.8 MPa water-pressure range for luxury commercial washrooms.
How should the motion-sensor detection zone be commissioned?
Complete sensor testing after the basin, backsplash, mirror, lighting, soap dispenser,
and surrounding accessories are installed. Verify repeated activation from normal
hand-washing positions and confirm that reflective surfaces, nearby movement,
cleaning activity, or objects outside the intended sensing area do not create false triggering.
How should the 1.58 GPM flow rate be verified during commissioning?
Flush the supply line before final connection, inspect the inlet path for debris,
fully open the service stop, and perform a timed volumetric flow test under normal
dynamic pressure. Restricted tubing, sediment, trapped air, or partially closed
upstream valves can reduce the specified 1.58 GPM / 6 L/min discharge.
How should the 4.92-inch swan-style spout be coordinated with the basin?
Position the single mounting hole so the 4.92-inch spout projection directs water
toward the primary washing zone and basin drain. Confirm the actual stream landing
point under operating pressure before final tightening to minimize splash and preserve
comfortable hand clearance below the sculpted outlet.
How should the Chrome finish be cleaned without scratching or hazing it?
Remove fingerprints, water spots, and soap residue with a soft damp microfiber cloth,
then dry the faucet immediately. Use diluted pH-neutral soap only and avoid abrasive pads,
acidic descalers, bleach, ammonia, steel wool, polishing powders, aggressive metal polish,
and concentrated disinfectants.
