Infrared technology recognizes hand movement inside a factory-set 25-centimeter field, opening the supply without physical contact. Solid brass shapes the body, spout, and valve housing, supporting reliable performance during demanding daily operation. An included hot-and-cold mixer enables temperature adjustment, complemented by a controlled 1.3 GPM output and 0.05–0.7 MPa pressure range. Flexible AC 110V or DC 6V power arrangements accommodate varied project conditions. IP56 enclosure protection and tolerance for 1–45°C ambient temperatures further strengthen functional readiness. Blush-toned metal brings a jewel-like warmth to private clubs, boutique accommodations, fine dining destinations, spa lounges, and signature workplace suites. Its slender form harmonizes with pale marble, terrazzo, smoked glass, natural timber, and softly illuminated mirrors. Rather than appearing purely utilitarian, the fixture contributes a graceful focal point that supports memorable guest impressions, restorative surroundings, and elevated everyday rituals. Design professionals benefit from an uncluttered single-hole, deck-mounted format suited to bespoke vanity compositions. Countertop compatibility extends to 1-5/8 inches, allowing integration across numerous surface specifications. ADA compliance helps advance inclusive planning without disrupting visual continuity. BIM files, technical sheets, three-dimensional renderings, installation manuals, maintenance references, and warranty materials simplify documentation from early selection through construction administration. This coordinated solution combines responsive sensing, mixed-temperature convenience, resilient fabrication, efficient delivery, and expressive color within a refined commercial package.

FONTANA RIO™ TOUCHLESS LINE

Fontana Rio Touchless Faucet FAQs

Commercial tall-profile infrared touchless faucet with solid brass construction, 1.3 GPM water-saving performance, single-hole deck mounting, hot and cold mixing, AC/DC power capability, adjustable sensing, and ADA-compliant hands-free operation.

✥ Sensor Commissioning Procedure? +

Complete sensor commissioning after the basin, countertop, backsplash, mirror, and surrounding accessories are fully installed. The factory detection zone is approximately 25 cm or 10 inches. Verify reliable activation and adjust the sensing field where required to prevent unintended response from reflective surfaces.

◇ Hydraulic Checks During Installation? +

Flush the DN15 water supplies before final connection, inspect the built-in strainer for debris, verify all hoses and fittings are secure, and confirm stable dynamic pressure before commissioning the electronic valve assembly.

◯ 1.3 GPM Flow Rate Verification? +

Verify approximately 1.3 GPM under normal dynamic operating conditions. If output becomes restricted, inspect the outlet, supply hoses, built-in strainer, service stops, and available water pressure for sediment, mineral buildup, or installation debris.

↻ Continuous Water Flow Diagnostics? +

Clean the infrared sensor surface and remove stationary or reflective objects from the sensing field. Verify stable power and inspect the solenoid and water path for debris or incomplete closure if water continues flowing after hands leave the detection zone.

⌁ Sensor Detection Range? +

The live specification lists a factory-set detection zone of approximately 25 cm or 10 inches. Final sensing should be verified with the completed basin installation so normal hand movement activates the faucet without false triggering from the sink or countertop.

⌂ Hot and Cold Mixer Commissioning? +

A hot-and-cold mixer is included with the Rose Gold Rio configuration. Flush both supply lines before final connection, confirm balanced pressure, establish the required mixed-water temperature, and perform repeated activation cycles to verify stable delivery.

⚡ AC and DC Power Options? +

The Rio supports AC110V and DC6V power configurations. Protect the power supply and control components from moisture and maintain service access beneath the countertop. Batteries are not included.

⌕ Routine Commercial Maintenance? +

Periodically clean the sensor surface and faucet outlet, inspect the built-in strainer and supply connections, remove mineral deposits, and verify dependable automatic shutoff. Clean decorative finishes using a soft cloth and mild non-abrasive cleaner.

‹ ›

Rose Gold

Rose Gold Chrome Brushed Nickel Gold Brushed Gold Gun Metal Gray Champagne Oil Rubbed Bronze Matte White Matte Black Antique Brass

♧

1.3 GPM Water Efficient

◇

Solid Brass Durable Construction

⌁

25 cm Sensor Infrared Detection

⚙

AC / DC Power Flexible Installation

◇

ADA / IP56 Commercial Grade
