FontanaPulseAir X™ Brushed Nickel Automatic Sensor Hand Dryer FAQ
Mounting Stability, Motor Selection; Brushed Nickel Maintenance
The FontanaPulseAir X™ Brushed Nickel automatic hand dryer combines a wall-mounted brass body, infrared touchless activation, HEPA-filtered airflow, 95 m/s air velocity, 70 dB operation at two meters, and selectable brush or brushless motor configurations.
How should the wall structure be prepared before mounting the hand dryer?
Secure the mounting plate to structural blocking or approved heavy-duty anchors rather than relying on finish material alone. Confirm that the dryer remains level and rigid under operating vibration, with sufficient clearance for electrical access, filter replacement, ventilation, and future servicing.
When is a brushless motor preferable to the standard brush motor?
A brushless motor is generally better suited to high-traffic facilities where longer service intervals, reduced internal wear, and consistent daily operation are priorities. A brush motor may suit lower-use installations where initial equipment cost is more important than extended maintenance intervals.
What can cause the dryer to operate louder than its specified 70 dB level?
Loose mounting hardware, contact between the housing and wall surface, a restricted air intake, loaded HEPA filter, internal debris, or motor-bearing wear can increase vibration and sound. Inspect mechanical mounting and airflow restrictions before adjusting or replacing the motor assembly.
How should the Brushed Nickel housing be cleaned without changing its grain pattern?
Wipe in the direction of the brushed grain using a soft damp microfiber cloth, then dry the surface completely. Use diluted pH-neutral soap only and avoid abrasive pads, steel wool, acidic cleaners, bleach, ammonia, and polishing compounds that may create bright or uneven areas.
