FontanaLuxeFusion Automatic 3 in 1 Soap, Faucet & Dryer Brushed Nickel
The FontanaLuxeFusion™ Brushed Nickel 3-in-1 Automatic System presents a premium wall mounted system combining a sensor activated tap, sensor activated soap dispenser and a fast dryer in one cohesive body. Designed for the modern commercial interior, it has striking style, hygiene & durability. Heavy-duty brass construction with a brushed nickel surface finish resists stains, fingerprints and tarnishing. The water outlet uses a ceramic cartridge with a constant flow despite plumbing pressure and temperature variations, to avoid leaking from unforeseen plumbing issues. The built-in soap dispenser has a generous one-litre reservoir, which means refilling will not prolong the lick-time for a customer in heavy user environments. The drying is achieved via a drying module with a 1300W brushless motor, with a maximum speed of 38,000 RPM. Speeds of up to 90 mps can provide a drying time of 10–15 seconds from the last water droplet on the hands. Its maximum performance creates a sound level of nearly 75dB, which makes it acceptable for all washroom environments if considered. On both the tap and dryer, a built-in smart infrared (IR) sensor will provide a fully touchless washroom experience. A built-in HEPA filter purifies the air that is blown out as well as the water that comes from the tap; there's also AC/DC versatility for installations. It is ADA compliant, which means accessibility; every modern store, office building and washroom can look sleek, how you always wanted it to. The brushed nickel finish is also a simple, elegant enhancement without excessive loudness to modern washroom spaces. FontanaLuxeFusion™ brings robust durability, speed & likability in one elegant, innovative piece of hardware.
Integrated Faucet, Soap & Dryer Combo
- Brand Name: FontanaShowers®
- Model Number: FS9901BN
- Finish: Brushed Nickel
- Feature: Touchless Faucet, Soap Dispenser & Dryer (3-in-1)
- Main Material: Solid Brass-Metal
- Valve Material: Ceramic
- Installation Type: Wall Mounted
- Surface Treatment: Polished
- Motor: Brushless (for dryer)
- Voltage: 220–240V / DC6V (AC & DC Compatible)
- Frequency: 50Hz
- Total Power: 1300W
- Standby Power: 1W
- Water Pressure (Faucet): 0.05–0.6 MPA
- Operating Temperature (Water): 0.1–50°C
- Soap Volume Capacity: 1L
- Sensing Distance: 16–32 cm
- Dryer RPM: 38,000
- Hand Dryer Air Speed: 90 m/s
- Dryer Temperature: 30–40°C
- Noise Level: 75 dB
- Filter: HEPA
- Hand Dryer Dry Time: 10–15s
- Tap Height: Water Tap: 20 mm | Dispenser: 20 mm | Dryer: 20 mm
- Tap Width: Water Tap: 40 mm | Dispenser: 40 mm | Dryer: 46 mm
- Tap Depth: Water Tap: 220 mm | Dispenser: 220 mm | Dryer: 240 mm
- Motor Case Height: Water Tap: 145 mm | Dispenser: 307 mm | Dryer: 290 mm
- Motor Case Width: Water Tap: 116.5 mm | Dispenser: 90 mm | Dryer: 210 mm
- Motor Case Depth: Water Tap: 85.5 mm | Dispenser: 106 mm | Dryer: 190 mm
- ADA Compliant
|
|
|
 |
|
 |
|
